1. Integral absorption refrigeration/power generation system,
2. Pressurised hot water heat source simulator,
3. Cooling water unit
4. Brine solution secondary refrigeration unit.
5. All the high and low temperature components are insulated to minimise heat loss.

The absorption refrigeration / power generation system includes both cooling and power generation subsystems.

Absorber : Vertical falling film type, 67 kW heat duty

Condenser : Shell and Tube type, 35 kW heat duty

Evaporator : Vertical shell and Tube type, 35 kW heat duty

Generator : Shell and helical Coil type, 64 kW heat duty

Generator heat exchanger : Shell and helical Coil type, 12 kW heat duty

Rectifier : Shell and helical Coil type, 11 kW heat duty

Solution heat exchanger : Shell and helical Coil type, 58 kW heat duty

Condensate pre-cooler : Shell and helical Coil type, 3.4 kW heat duty

1. Inside Dia:55.88 cm Chamber
2. Depth:83.82cm Chamber
3. Volume:0.198 Cu.meter
4. Min.temp:-1850C ,
5. Max.Temp:1600C
6. Liquid N2 use at -1850C

1. Capacity: 150 Ton
2. Indoor Dry Bulb Temperature: 4 to 40°C
3. Indoor Dew Point Temperature: 2 to 30°C
4. Outdoor Dry Bulb Temperature: -26 to 55°C
5. Outdoor Dew Point Temperature: -15 to 35°C
6. Indoor and Outdoor Room Air Flows: Up to 34,000 m3/hr

1. Accuracy: ± 5 to ± 10% Thermal Conductivity/Resistivity ± 10% Specific Heat ± 10% Thermal Diffusivity
2. Measurement Speed:1, 2, 5, & 10 min. read times depending on measurement type (see user’s manual for more information).
3. Data Storage: 4,095 readings, flash memory Operating Environment of Sensors: -50° to 150°C

1. Temperature range: -150°C to 2400°C. Tungsten furnace. (RT to 2400°C)
2. Heating and cooling rates: 0.001 K/min to 50 K/min
3. Weighing range: 35000 mg.
4. TG resolution: 0,1 µg (over entire weighing range)
5. DSC resolution (depending on sensor type): Switch valve for 2 purge gases and 1 protective gas

1. High sensitivity heat flux design A stable and reproducible baseline
2. Temperature range: -150 C to 725 C Exceptional temperature accuracy Preheated purge gases Large dynamic range Heating rates up to 200 C/min Superior performance with rugged reliability 24-bit high resolution with USB or RS232 interface
